La serie Essential Plus Power tienen una eficiencia de hasta un 87%, cumple con la Certificacion 80 PLUS Bronze. Debido a la alta eficiencia de la serie EPP, puede reducir los costos de consumo eléctrico y brindar al mismo tiempo un alto rendimiento.
La serie Essential Plus Power está diseñada para brindar una solidez y confiabilidad con potencia real y continua. Con su alto efficiencia y robustes para alimentar sistemas con placas graficas de ultima generacion. Con el sistema de Multiprotecciones para evitar cualquier daño en los dispositivos conectados.
La Essential Plus Power de 650 W cuenta con un único Raíl rubusto y dedicado de +12V 55A que permite con una sencilla configuración disponer de toda la corriente disponible en esa línea, ofreciendo una mayor compatibilidad con los componentes y las tarjetas gráficas de ultima generación.
GENERAL
- Serie Essential Plus
- Modelo EPP650-PS
- Part Number EPP650-PS
DC OUTPUTS RANGE
- Entrada CA (A) 10-6A
- Frecuencia Entrada CA (Hz) 50-60Hz
- Voltaje Entrada CA (Vca) 115-240Vac
- Corrección del Factor de Potencia >.99
- Eficiencia a Carga Típica < 90%
RANGO DE CARGA
- Potencia Max. de Salida (W) 650 W
- Salida Max. de Corriente -12V (A) 0,5 A
- Potencia Max. -12V (W) 6 W
- Rail de +12V Single
- Salida Max. de Corriente +12V1 (A) 48 A
- Potencia Max. +12V1 (W) 576 W
- Salida Max.de Corriente +12V2 (A)
- Potencia Max. +12V2 (W)
- Salida Max. de Corriente +3.3V (A) 24 A
- Salida Max. de Corriente +5V (A) 24 A
- Potencia Max. +3.3V & +5V (W) 120 W
- Salida Max. de Corriente +5VSB (A) 3 A
- Potencia Max. +5VSB (W) 15 W
CONECTORES
- Motherboard 20+4pines 1
- CPU +12V 4pines
- CPU +12V 4+4pines 1
- CPU +12V 8pines
- SATA 5pines 8
- Molex 4pines 4
- Floppy 4pines 1
- PCI-E 6pines 1
- PCI-E 6+2pines 4
ESPECIFICACIONES FISICAS
- Tamaño del Fan Cooler (mm) 140mm Sleeve Bearing
- Entrada de Flujo de Aire (CFM/min)
- Dimensiones de la fuente (mm) 160mm (L) x 150mm (W) x 86mm (H)
- Peso Neto (gr) 2,00 Kg
- Pintura de Terminacion Sandy Black
- Factor de Forma ATX
- Peso Bruto (gr) 2,25 Kg
- Dimensiones de la Caja (mm) 260mm (L) x 210mm (W) x 100mm
PROTECCIONES
- Proteccion de Sobre Corriente (OCP)
- Proteccion de Sobre Potencia (OPP) Si
- Proteccion de Sobre Temperatura (OTP)
- Proteccion de Sobre Voltaje (OVP) Si
- Proteccion Contra Corto Circuito (SCP) Si
- Proteccion de Bajo Voltaje (UVP) Si
TECNOLOGIAS & CARACTERISTICAS
- Modular
- AMD Crossfire Preparada
- NVIDIA SLI Preparada
- DC to DC Converter Si
- 105 C Japanese Capacitor Todos
- Solid State Capacitors
- Power Factor Corrector Activo
- Modular Flat Cables
- Sleeve Cables
- Sleeve Natives Cables Si
- Power Cord Certified Si
- ECO Intelligent Control System
- Vertical Double Layer Main Transformer
CERTIFICATIONS & STANDARDS
- 80 Plus Bronze
- Type ATX 2.3 EPS 2.92
- RoHs Si
- Energy STAR
- EuP Si
- C-tick Si
- CB Si
- CCC
- CUL
- FCC Si
- TUV
- UL Si
